INDUSTRIAL COMPUTERS
|
Model / Order code
|
MP6-126A - 12.1” Display
|
MP6-156A - 15.1” Display
|
MP6-176A - 17.1” Display
|
|
Price
|
R9,500.00
|
R10,500.00
|
R 11,500.00
|
|
Operating Software
|
4HR-0049
|
Micosoft Windows 8 Home Basic— 32Bit
|
R 1048.00
|
|
FQC-05919
|
Micosoft Windows 8 Professional—32Bit
|
R 1,800.00
|
|
Displaying area
|
TFTLCD 12.1 "
|
TFTLCD 15.1 "
|
TFTLCD 17.1"
|
|
Resolution
|
800*600
|
1024*768
|
1280*1024
|
|
Colour Resolution
|
262K
|
16.2M
|
16.2M
|
|
Contrast Radio
|
250:1
|
450:1
|
500:1
|
|
Brightness
|
150cd/m2
|
250cd/m2
|
300cd/m2
|
|
Touch Screen
|
Maple Touch Five-wire Resistive Touch Screen (Hitting life: +35 million times for each point)
|
|
VGA Port
|
DB-15 port
|
|
Touch screen Controller
|
USB/COM (Optional)
|
|
DC Adapter
|
DC12V 5A
|
|
Standard Collocations
|
|
Main board
|
Intel 945GSE
|
|
CPU
|
1.6G (ATOM N270)
|
|
Memory
|
DDR 1G, 320G/16G industrial SSD
|
|
HDD
|
60G
|
|
USB Pot
|
3 UNITS
|
|
RS232 Pot
|
2 UNITS
|
|
Audio interface
|
AC97 Audio (1 sound input, 1 sound output)
|
|
Network Interface
|
10/100/1000Mbps high speed Ethernet network (wireless network card optional)
|
|
IE1394
|
2 Units
|
|
Operating and Storage Temperature Ranges
|
|
Operation temperature
|
-10 C° ~ 35 C°
|
|
Storage Temperature
|
-20 C° ~ 60 C°
|
|
Others
|
|
Installation
|
Hanging, Desktop VESA, Mounting Bracket Available for Panel Mount.
|
|
Power Supply
|
110V ~ 240V AC
|
|
Base Dimensions
|
L*W*H (197*222*146)mm
|
|
Outline Dimensions
|
L*W*H (300*246*66)mm
|
L*W*H (366*286*65)mm
|
L*W*H (403*300*72)
|
|
Weight NET/GW
|
5.3/6.9kg
|
6.2/7.6kg
|
7.0/9.1kg
|
|
Wall Mount Bracket
|
ORDER CODE
|
LAXTSPTPC-WMB
|
R 500.00
|
Panel Mount Kit |
PMK12 - R 400.00 |
PMK15 - R 450.00 |
PMK17 - R 507.00 |
PLEASE NOTE:
PRICES ARE FOR INDICATION PURPOSES ONLY AND SHOULD BE CONFIRMED BY OFFICIAL QUOTE
